Electric Gas Automatic Cashew Nut Grader Cashew Nut Cracking Sorting Roasting Peeling Separator Cashew Nut Production Line Nut Machinery
Overview Product Description electric gas automatic cashew nut grader cashew nut cracking sorting roasting peeling separ
Description
Basic Info
| Model NO. | ACPL |
| Application | Cashew |
| Customized | Customized |
| Name | Cashew Prodution Line |
| Key Words | Nuts Processing Machinery |
| Model | Acpl |
| Production | Customized |
| Voltage | Customized |
| Heating Method | Electric or Gas or Steam |
| Power | According to Production Capacity |
| Number of Production Steps | 8 |
| Function | Automatic |
| Advantage | High Efficiency |
| MOQ | 1 |
| Regular Production | 400-500kg/H |
| Apply | Cashew |
| Material | Carbon Steel |
| Package | Wooden Case |
| Transport Package | Wooden Case |
| Specification | 200-3000kg/h |
| Trademark | Auris |
| Origin | Henan, China |
| Production Capacity | 200-3000kg/H |
Product Description
electric gas automatic cashew nut grader cashew nut cracking sorting roasting peeling separator cashew nut production line nut machinery
This production line is used to process raw cashew nuts. The machines are mainly customized according to customer requirements. The general main processing flow is: classifier---cooking machine---shelling machine---shell and nut separator---nut drying machine---peeling machine---nut classifier---baking into various Nuts in various flavors.
Cashews grow unevenly in size. In order to improve the integrity rate of shell opening, they are generally divided into 3-5 grades, and we can customize the grades according to customer requirements. The general level will be divided into four levels according to the width: below 21mm, 21-23mm, 23-25mm and above 25mm. The machine consists of transmission structure, hierarchical structure, machine frame and other parts.
1. Professional technology to build the machine, high efficiency, the output can be customized according to customer requirements.
2. Using Japanese imported bearings, smooth and durable.
3. The equipment is easy to use and easy to operate.
4. The production line can be customized according to your needs.
2. cashew steaming cooking machine
Cashew nut cooking machine is a device that cooks cashew nuts according to the characteristics of cashew nuts. Cashews are special because there is no gap between the shell and the kernel. By cooking, the gap between the husk and the nut can be enlarged, and the shell opening rate and the whole kernel rate of the husk can be effectively improved.3. cashew nut peeling machine
| Model | ABK-1 |
| Production capacity | 150--200KG |
| Voltage | 380v/220v 50hz, 3kw |
| Open rate | 90--95% |
| Unopened rate | 3% |
| Control method | button control |
| breakage rate | <5-10% |
| Dimension: | 1.4*1*1.55M |
| Weight | 300KG |
4. shell and nut separator machine
This machine is mainly used for the separation between the shells and nuts of cashew nuts, and is a supporting equipment for the shelling machine.| Model | AFL-1 |
| Voltage | 380v, 50hz, three phases |
| Power | 1.1kw |
| Production capacity | 500kg |
| Dimension | 1.9*0.8*1.4M |
| Weight | 140kg |
5. nut drying machine
The drying box is divided into high temperature zone, low temperature zone and cooling zone. The materials are successively subjected to high temperature, low temperature drying (baking), and three temperature zones, and the finished product is cool, which is convenient for reprocessing, packaging or storage. The multifunctional automatic drying box has the characteristics of high drying efficiency, low energy consumption and uniform heating.6. nut peeling machine
This machine adopts the pneumatic principle to process the peeled nuts into nuts without any damage. After the nuts are dried, the equipment can be used for peeling, the peeling rate reaches more than 95%, and the nuts and peels are automatically separated.1. Using a specially designed peeling principle, during the peeling process, the nuts are completely free from the blade and hardness friction, so it can ensure the integrity of the processed product and no pollution.
2. It has the characteristics of short-term automatic feeding, peeling, discharging, automatic and consistent operation, practical, power saving, small size, high production efficiency, easy maintenance and cleaning, and low failure rate.
3. Equipped with an automatic feeding device, the nut peel is automatically separated.
7. nut grading machine
The drum type cashew nut grading machine is a drum segment, and the gap size is classified. The machine is composed of transmission structure, drum structure, machine frame, etc. It is mainly used for the size grading of nuts, generally divided into 3 levels, and the machine can also be customized according to your requirements.8. nut baking machine
Roller baking machine is used for baking hazelnut, almond, pine nut, peanut and other foods. The advantages are simple operation, compact structure and high efficiency, so it is more suitable for small and medium-sized food processing enterprises. Roller baking machine adopts rotary rolling cage and special high-quality infrared catalytic burner to realize flameless catalytic combustion of natural gas and liquefied petroleum gas. Roller baking machine is equipped with automatic temperature control device. In the process of baking, the object to be baked is continuously pushed by the propulsion device in the cylinder to form an uninterrupted cycle, which makes it heated evenly and effectively ensures the baking quality.Company Profile
